LEDBOX - Led Driver - 1 Output RGBWWA - DMX controllable - 6 x 6A

Reference A-LEDLB2108BM65

95.00 € VAT excluded €114.00 Tax included

Weight: 0.29 kg
Dimensions: 18.77 × 8.5 × 4.1 cm
Brand: LEDBOX
Protocol: DMX-RDM
Supply voltage: 12V, 24V

In stock

Guaranteed quality

Fast and secure delivery

Free in-store pickup!

Description of the product

Reference : LB-2108B-M6-5

Output type : 2xRGB / RGB+BV / 6xMonochrome

Type : Led DMX constant voltage driver

Max power/output : 6 x 144W (24V)

Max total power : 864 W (24V)

Max amperage : 6A per output (24V)

Power supply connection: Phoenix connector with screw terminal block, 2 inputs (removable)

DMX connection: RJ45 / XLR5

LED connection: Phoenix connector with screw terminal block, 5 outputs (removable)

DMX copy: Yes

Input voltage: 12V - 24V

Scanning frequency: 500Hz > 35kHz

DMX setting: 4-segment digit

RDM compatible: Yes (via DMX input)

Dimensions (mm): L187.7xW85xH41 mm

Weight: 290 g

Protection rating: IP20

Operating temperature: -20°C to +45°C

Use : Fixed installation

Warranty : 5 years
